Skyzone AtomRC Dragonfly Hex

Skyzone AtomRC Dragonfly Hex
Brand: Other
Category: Drones
  • 1: MCU: 168MHZSTM32F405
  • 2: IMU: MPU6000 Accelerametergyro
  • 3: Bulit in inverter for SBUS
  • 4: Supports 2-4S Lipo input
  • 5: Dimension: 30*39mm
  • 6: Weight: 6.8g

Skyzone AtomRC Dragonfly Hex - Price

Skyzone AtomRC Dragonfly Hex - Specs

Product Details

  • Features
    MCU: 168MHZSTM32F405
    IMU: MPU6000 Accelerametergyro (SPI)
    OSD: Betaflight OSD
    UART: 5
    PWM/Oshot Output: 6
    BEC: 3.3A / 5V
    Bulit in inverter for SBUS (RX2)
    Smartaudia & Tramp VTX Protocal Supported.
    WS2812 Led Strip: YES
    Beeper: YES
    RSSI: YES
    USB Connector: Type-C
    TARGET: ATOMRCF405
  • Specification
    Brand Name: SKYZONE
    Item Name: ATOMRC Dragonfly Hexa-copter HD FPV Racing Drone
    Flight Controller: ATOMRC Exceed F405 MINI
    Brushless ESC: ATOMRC Exceed 15A 6IN1
    Motor: 1404 3000KV
    VTX & Cam: Caddx Vista Nebula NANO
    Propeller: 3028
    Drone Weight: 180g (BNF VISTA version) / 185g (BNF-TBS version)
    Package Size: 22.5*26.5*8cm
    Package Weight: 380g (BNF VISTA version) / 385g (BNF-TBS version)
  • Package content
    BNF-VISTA Version:
    1 x Dragonfly Hexa-copter HD FPV Racing Drone

    BNF-TBS Version:
    1 x ATOMR Dragonfly Hexa-copter HD FPV Racing Drone
    1 x TBS Crossfire Nano RX

Our Rating

The overall rating is based on review by our experts

8.5 4.3 1
  • Design 8 / 10
  • Features 9 / 10
  • Performance 8 / 10
  • Connectivity 9 / 10

SKYZONE ATOMRC Dragonfly Hex Hexa-copter HD 3 Inch 4S FPV Racing Drone

The HEXplorer LR 4 from Flywoo and the Firefly Hex have put the hexa back in fashion. Here is the AtomRC Dragonfly Hex from Skyzone. It is a device for 3 inch propellers (3028) with 6 motors, brushless 1404 to 3000KV. Note that the arms are particularly and surprisingly long for 3 inch propellers! The flight controller is an AtomRC Exceed F405 Mini flashed with Betaflight, with 5 UART, a USB-C connector. It is associated with a 6 in 1 ESC of 15A. The device is equipped with a GPS placed at the rear.

It is provided by a Vista box and a Nebula Pro camera from Caddx, compatible with the Digital FPV System from DJI. Vista allows control with a DJI radio control. Skyzone also offers a version pre-equipped with a Crossfire Nano RX radio receiver from TBS. The weight of the device? 180 grams without the battery. Skyzone does not provide one and does not give a recommendation. It is likely that this device is intended to accommodate Lipo 4S of 850 to 1000 mAh, or Li-ion 4S of 3000 to 4000 mAh. The connector is an XT60.

The AtomRC Dragonfly Hex starts at $329.99 at Banggood, for availability on June 2, 2021. There is also a 5.8 GHz analog version, with a RunCam Split 3 Nano camera and a video transmitter capable of transmitting between 25 and 500 mW. It is offered from $235.99, still at Banggood. Its availability is scheduled for May 28, 2021.
