The Swiitol E18 Pro is an 18W (3*6W) laser engraving machine that is installation-free and designed with an integrated structure. The overall frame of the machine is made of aluminum alloy, allowing it to be used out of the box without any assembly required.
The machine has an electric power of 130W and a laser output optical power of 15-18W. It has an engraving ruler of 365x305mm and a maximum engraving speed of 36000mm/Min. The spot size of the laser is 0.08×0.08mm.
The Swiitol E18 Pro uses a second-generation blue laser packaging process, which compresses the laser spot and significantly improves cutting capabilities. This process increases the cutting capacity by 20% compared to machines of the same level. The ultra-fine laser focus area is reduced to 0.08×0.08mm, allowing the high-density laser to easily cut 15mm thick Pine Wood and 15mm thick black acrylic by multiple cuts.
The machine’s structure is designed for stability and high speed. The bottom frame is formed in one piece, and the X-axis metal adopts a double-axis guide rail structure to work with small vibration, ensuring that the machine does not shake when running at a high speed of 36000mm/Min. The machine also uses a tank chain wire binding scheme for a more stable structure and improved wire life.
The Swiitol E18 Pro is equipped with a red light cross positioning module for faster and more accurate positioning of the engraving range. It is compatible with various mature engraving software, such as LaserGRBL and LightBurn, and supports Win XP/Win 7/Win 8/XP/Win 10. It also supports the Mac system (LightBurn) and engraving file formats, including NC, BMP, JPG, PNG, DXF, etc.
For safety, the machine is equipped with an emergency stop button, a reset switch, and a limit switch. It also features a new non-clogging laser with a built-in tool-free focusing module and a built-in air assist system, without wire interference.
Price
Honestly, 18W blue diode lasers are not common in the laser engraving market, it’s somewhere between 10W and 20W, so it has decent engraving and cutting capabilities. The price is also very favorable, on the official website, you can pick up the Swiitol E18 Pro for $389, delivery from EU, Free Shipping, shipment time is 3-5 business days, and Subscribe to the Swiitol store, you can get a 5% off coupon.
