DJI Osmo Pocket Gimbal PTZ Camera

DJI Osmo Pocket Gimbal PTZ Camera
Brand: DJI
Category: Outdoors
  • 1: Osmo Pocket PTZ Camera
  • 2: 3-axis Mechanical Stabilization Gimbal
  • 3: Small Body, Outstanding Performance
  • 4: Image New Time
  • 5: Micro Machined Gimbal
  • 6: T-type Heat Dissipation Design

DJI Osmo Pocket Gimbal PTZ Camera - Specs

Product Details

  • Features
    - Operating ambient temperature: 0 - 40 Deg.C
    - Main functions: FPV mode, smart follow, track delay, dark light shooting, automatic panorama, etc.
    - Firmware upgrade: automatic upgrade by downloading DJI Mimo APP
    - Memory card: no ( mainly recommended for the mainstream brand Micro SD with a write speed of 15MB/s or more )
    - Built-in microphones: two, with built-in audio noise reduction algorithm to improve the recording quality
    - Waterproof function: no. It is recommended to use a waterproof case for use in a water environment
    - Remote connection: support Bluetooth or WiFi, but it needs to be connected to the wireless module for connection ( not included, you need to prepare it separately )
  • Specification
    Brand: DJI
    FPV Equipments: Camera,Gimbal
    Functions: Video

    Product size: 38.4 x 28.6 x 36.9mm
    Lens Viewing angle: 80-degree, aperture: f/2.0
    ISO range Photo: 100 - 3200, Video: 100 - 3200
    Electronic shutter speed: 8s - 1/8000s
    Photo maximum resolution: 4000 x 3000
    Photo shooting mode: single photo, normal video, panoramic photo, static delay, track delay
    Video resolution:
    - 4K Ultra HD: 3840 x 2160 24 / 25 / 30 / 48 / 50 / 60p
    - FHD: 1920 x 1080 24 / 25 / 30 / 48 / 50 / 60p
    Video mode: normal shooting
    Video storage maximum stream: 100Mbps
    Support file system: FAT32 ( equal tor less than 32 GB), exFAT ( more than 64 GB )
    Picture format: JPEG / JPEG + DNG
    Video format: MP4 / MOV ( MPEG-4 AVC / H.264 )
    Support memory card: Micro SD, maximum support 256 GB ( not included )
    Audio output: 48KHz, AAC
    Image sensor: 1/2.3 inch CMOS, effective pixel 12 megapixel

    Controllable range of rotation Translation:
    Pan: - 230-degree to 50-degree
    Pitch: - 95-degree to 50-degree
    Roll: + / - 45-degree
  • Package content
    1 x DJI Osmo Pocket Gimbal PTZ Camera
    1 x 8 Pin Connector
    1 x Type-C Connector
    1 x USB Cable
    1 x Storage Box

Our Rating

The overall rating is based on review by our experts

8.8 4.4 1
  • Design 9 / 10
  • Features 8 / 10
  • Connectivity 9 / 10
  • Performance 9 / 10

DJI Osmo Pocket Gimbal PTZ Camera 4K 60fps Smart Shooting

As expected, the company DJI introduced Osmo Pocket. The novelty differs from other representatives of the series in reduced dimensions: with dimensions of 121.9 x 36.9 x 28.6 mm and a mass of 116 grams, it can easily be carried in a pocket.

In a camera mounted on the universal joint, a CMOS 1 / 2.3-inch format matrix with a resolution of 12 megapixels is installed. A lens with an aperture of F / 2.0 provides a viewing angle of 80°. The range of exposure covers values ​​from 8 to 1/8000 s, the range of sensitivity from 100 to 3200 ISO. Photo can be taken in four modes (Single Shot, Panorama, Timelapse and Motionlapse), but the maximum video recording capacity is 4K at 60 fps Interestingly, when lowering the resolution to Full HD, the maximum frame rate is still the same 60 fps.

Material is stored using SD cards up to 256 GB (there is only one slot), and the camera is powered by a battery with a capacity of 875 mAh. The claimed autonomy reaches 140 minutes.

DJI Osmo Pocket Gimbal PTZ Camera

The processor, which is responsible for image processing, is hidden in the handle and is cooled passively. Focus and settings management is assigned to a small touch screen, but you can also use a smartphone screen as a viewfinder.

A feature of the Osmo Pocket is the presence of a connector for connecting modules – it is located under the cover above the video recording button. In general, DJI offers a lot of accessories for the novelty: from a carrying case and a controller with a circular selector to a cover for underwater shooting and USB-C and Lightning adapters.
