The popular TV Box X99 Max with its powerful RK3399 platform has been updated and now comes with the latest Amlogic S922X chip. It comes with 4GB of LPDDR4 RAM and 128GB of built-in EMMC file storage, making it one of the most powerful set-top boxes in its price range, along with a high-performance processor.
The TV Box X99 Max includes the SoC Amlogic S922X, a 12nm six-core processor containing 4 ARM Cortex-A73 processors that can reach 1.8GHz and 2 ARM Cortex-A53 processors that reach 1.9GHz. The graphics processor is an ARM Mali-G52 MP6 with a maximum frequency of 846 MHz, compatible with OpenGL ES 3.2 and Vulkan 1.0, which allows you to easily run powerful games such as PUBG. Operated by the Android 9.0 operating system.
The VPU is Amlogic Video Engine (AVE-10) with all types of support for HDR, Dolby Vision, Advanced HDR10, HDR10+, HLG, PRIME HDR and support for REC709 / BT2020 profiles. There is also an integrated digital audio DAC. The RAM is 4GB LPDDR4 and the built-in memory is 128GB eMMc and can be expanded with a microSD card reader on the right side of the case.
As far as wireless communication is concerned, X99 Max supports dual-band WiFi and Bluetooth 5.0 with internal antenna. There are 2 USB ports on the case: 3.0 and 2.0, Gigabit Ethernet, SPDIF digital audio output, HDMI 2.0 and 3.5 mm audio jack.
