Happymodel Crux35 Analog

Happymodel Crux35 Analog
Brand: Other
Category: Drones
  • 1: Ultra-lightweight 3.5-inch
  • 2: HD video transmission
  • 3: Integrated ExpressLRS SPI receiver
  • 4: Frsky SPI D8/D16 receiver
  • 5: High efficiency EX1404 power system
  • 6: Naked Gopro or SMO4K

Happymodel Crux35 Analog - Price

Happymodel Crux35 Analog - Specs

Product Details

  • Features
    - Ultra-lightweight 3.5-inch BNF FPV Freestyle Drone
    - HD video transmission and analog video transmission are optional
    - Integrated ExpressLRS SPI receiver or Frsky SPI D8/D16 receiver
    - High efficiency EX1404 power system
    - Can be equipped with Naked Gopro or SMO4K
    - Support 3-4S battery 4S 750mah battery is recommended, maximum support 4S 1100mah
  • Specification
    Brand: Happymodel
    Model: Crux35 Analog / Crux35 HD
    Wheelbase: 150mm
    Weight: 87g ( Analog); 108g ( HD)
    Size: 130mmx130mmx45mm (without propellers)
    Version Optional: Analog / HD
    Receiver optional: SPI ExpressLRS 2.4GHz / SPI Frsky D8/D16 (S-FHSS compatible)
    Camera option: HD version Nebula+Vista
    Analog version Ant+OVX303 VTX
    Flying time: 9min~15min 4s 750mah battery
  • Package content
    1x Crux35 Frame
    1x Analog FPV Camera Caddx Ant
    1x Happymodel OVX303 5.8G analog VTX
    4x Happymodel EX1404 KV3500 brushless motor
    1x HQProp T3.5X2X3Grey (4cw+4ccw)
    1x Screw Driver
    1x Buckle for battery
    Option1: ELRS X1 flight controller
    Option2: CrazyF411 flight controller

Our Rating

The overall rating is based on review by our experts

7.3 3.7 1
  • Design 7 / 10
  • Features 8 / 10
  • Performance 7 / 10
  • Connectivity 7 / 10

Happymodel Crux35 Analog Ultralight FPV Racing Drone

This mini racer is intended for drone racing: it is a device equipped with 3.5-inch propellers that weighs, without its battery, 87 grams for the version with analog video feedback, and 108 grams for the digital version.

The device is based on a minimalist carbon structure which hosts brushless motors EX1404 at 3500KV. The flight controller, flashed with Betaflight, is available in two versions. One offers an SPI radio receiver compatible with FrSky D8 and D16, the other an ExpressLRS 2.4 GHz receiver, also SPI. The motors are driven by a 4 in 1 ESC (the amperage is not indicated by the data sheet). The propellers are 3.5 inch HQProp T3.5x2x3. Happymodel recommends 4S batteries of 750 mAh for an autonomy that can reach 9 minutes.

The model with digital video return is equipped with a Nebula Nano camera and a Vista box compatible with the DJI Digital FPV System. The model with analog video return integrates a Caddx Ant 1200TVL camera and a 5.8 GHz analog video transmitter OVX303 capable of transmitting at 25 mW, but also up to 300 mW.
